Machine Frame
Heavy-duty welded steel machine frame with precision mounting surfaces and integrated cable management channels.
Back to Portfolio
The Challenge
Design a rigid machine frame capable of maintaining alignment under dynamic loads while simplifying on-site assembly.
Our Solution
Created a modular welded frame design with precision-machined mounting pads and pre-routed cable channels for clean integration.
Results
- ±0.05mm mounting surface accuracy
- Reduced on-site assembly by 3 days
- Full weldment drawings with WPS
Project Details
- Client
- Precision Manufacturing Co.
- Year
- 2024
- Category
- Manufacturing
- Services
- Mechanical CAD DesignSheet Metal DesignManufacturing Drawings
